Thuraya Commander NEO

Commander NEO enables secure on-the-move communications for vehicles and rail platforms operating in demanding environments. Its solid-state design ensures stable satellite connectivity without mechanical wear, while integrated voice and data services reduce system complexity. Designed for fleets and mobile command platforms, Commander NEO provides dependable broadband performance wherever operations require continuous mobility.

Features

On-the-Move Broadband Connectivity

Maintains continuous L-band connectivity while vehicles or trains are in motion.

Powered by Thuraya-4

Delivers up to 1024 kbps throughput with reliable performance at low elevation angles.

Solid-State, No Moving Parts

Electronically steered design ensures durability, reliability, and minimal maintenance.

Ruggedised for Extreme Environments

IP68 and MIL-STD certified to withstand dust, rain, vibration, heat, and salt fog.

Integrated Communications Stack

Combines IP data, VoIP, Wi-Fi access point, and routing in one compact unit.

Vehicle-Ready Installation

Low-profile dome with flexible mounting and hybrid power connectivity for clean installs.

Technical specifications

Dimensions

Height: 11.7 cm (with 3 cm spacers)
Width: Ø 32.1 cm

Weight

4.8 kg

Data Capabilities

Up to 1024 kbps (Rx / Tx)

Voice

Standard VoIP
Embedded SIP Server
PPT Push-To-Talk with Mobile
Neo M

Frequency Range

Tx: 1626.5 – 1660.5 and 1668 – 1675
Rx: 1518.0 – 1559.0

GNSS

GPS, Galileo, Beidou, Glonassr

Languages

EN, AR, FR, DE, ES, RU, JP, CN

Approvals

CE, RED, RoHS, WEEE, FCC, UL, RCM, Thuraya Type Approval

Environmental Conditions

Temperature
Operational (ambient): -25°C to +55°C (ambient)
Storage: -40°C to +85°C
Water and dust: IP68
MIL-STD-810G:
Method 503.6 (Temperature shock)
Method 505.6 (Solar Radiation)
Method 506.6 (Rain)
Method 507.6 (Humidity)
Method 509.6 (Salt Fog)
Method 510.6 (Sand and Dust)
Method 512.6 (Immersion)
Method 516.7 (Drop)
Method 524.1 (Freeze/Thaw)
EMI/EMC
MIL-STD-461H

Power

DC input range: 12 – 24 VDC (Max. 10.8 to 32 VDC)
Power (max): 70W (@10.5 – 32V)

Interfaces

WLAN Access Point: 802.11 b/g/n/ac
Ethernet: 10 / 100 / 1000 Mbps
Combined DC power and Ethernet connector
Combined connector providing DC power input,
ignition and Ethernet (PoE 802.3bt Type 3) connectivity.
User interface
One LED (Status), Web Interface,
Reset Button, SIM card connector

Other features

Space42 Connect App
Turns a Smartphone into a Satphone.
Available for Android / IOS.
Set-up and Router Functionality
Webserver, NAT Router, Admin control (password protected),
DHCP, Network Management, Remote Management, PPPoE

Package

• Commander NEO Terminal with 3cm spacers
• Quick Start Guide
• 6m hybrid DC power and Ethernet cable (open-ended)

Accessories

Connection Box for NEO
PoE Cable Connection cable (Cat5e), 6m
PoE Cable Connection cable (Cat5e), 15m open-ended
PoE Cable Connection cable (Cat5e), 25m open-ended
PoE Cable Connection cable (Cat5e), 50m open-ended
Hybrid DC/ethernet connection cable (6m open-ended)
Hybrid DC/ethernet connection cable (25m open-ended)
Magnetic Mount Kit

Downloads

Thuraya Commander NEO FactSheet
