Thuraya IP NEO C
High Speed Satellite Connectivity
Delivers up to 1024 kbps download and upload over the Thuraya 4NGS network for seamless real time applications
Built for On the Go Operations
Ultra-portable design with a total weight of 2.2 kg, built in battery, and IP55 rating for rugged mobility
Wi Fi Enabled
Integrated 802.11 b g n ac access point allows multiple devices to connect directly to the terminal
Smart Control with Thuraya Connect App
Manage the device through a smartphone with the Thuraya Connect App, available on Android and iOS
VoIP Ready
Supports standard VoIP with embedded SIP server and PoE port for external IP handset connection
Flexible Power Options
Runs on internal battery, DC input, or PoE input for ultimate field flexibility. Offers up to 38 hours standby
Versatile Mounting
Comes with options for tabletop use or pole mounting based on operational needs
Supports Critical Applications
Ideal for ISR, M2M, remote offices, perimeter security, telemedicine, and video transmission
User Centric Interface
Features LED indicators, power and reset buttons, and a secure web interface for configuration and diagnostics
225 x 225 x 61.5 mm
2.2 kg including battery
Up to 1024 kbps Rx Tx on Thuraya 4NGS
Up to 444 kbps Rx Tx on Thuraya 2 and 3
Standard VoIP
Embedded SIP Server
Tx 1626.5 to 1660.5 MHz
Rx 1525.0 to 1559.0 MHz
GPS, Galileo, Beidou, Glonass
English, Arabic, French, Portuguese, Spanish, Russian, Japanese, Chinese
DC Input 12 to 24
VDC PoE Input IEEE 802.3bt
PoE Output IEEE 802.3at
Power Consumption 4.5W standby, 22W transmit, 75W max during charging
Built in Lithium-ion Battery 10.8V 6.9Ah
Battery Life Up to 38 hours standby, 2 hours transmit at full speed
WLAN Access Point 802.11 b g n ac
Ethernet 2 x RJ45 PoE in and out
User Interface LED status lights, power and reset buttons, web interface
Operating Temp minus 21 to plus 55 degrees Celsius
Storage Temp minus 21 to plus 50 degrees Celsius
Ingress Protection IP55
Thuraya IP NEO Terminal with Embedded Lithium Ion Battery
AC DC Power Supply
Euro Power Cord and UK Converter
Ethernet Cable
Quick Start Guide
