Thuraya IP NEO M

IP NEO M is a fully portable satellite broadband solution built for rapid field deployment. With integrated Wi-Fi, VoIP, and routing capabilities, it allows teams to establish secure connectivity in seconds without external infrastructure. Its ruggedised, battery-powered design supports sustained operations in remote and unpredictable environments, making it ideal for disaster response, field missions, and temporary site setups.

Features

Portable, Grab-and-Go Design

Lightweight and compact with an embedded battery, enabling rapid deployment from backpack to broadband.

High-Speed L-Band Broadband

Delivers up to 1024 kbps IP connectivity powered by the Thuraya-4 satellite network.

Military-Grade Ruggedisation

IP68 and MIL-STD compliant for reliable operation in extreme environmental conditions.

Integrated Communications Hub

Supports voice (VoIP / VoLTE / Push-to-Talk), IP data, and local Wi-Fi in a single device.

Multi-Device Connectivity

Shares connectivity via built-in Wi-Fi and Ethernet with integrated routing capabilities.

Flexible Power Options

Operates on internal battery, DC power, PoE, or AC supply for extended field missions.

Technical specifications

Dimensions

225 / 225 / 61.5 mm (H/W/D)

Weight

2.2 kg including battery

Data Capabilities

Up to 1024 kbps (Rx / Tx)

Voice Support

Standard VoIP
Embedded SIP Server
PPT Push-To-Talk

Frequency Range

Tx (MHz) 1626.5 – 1660.5 and 1668 – 1675
Rx (MHz) 1518.0 – 1559.0

GNSS

GPS, Galileo, Beidou, Glonass

Languages

EN, AR, FR, PR, ES, RU, JP, CN

Approval

CE, RED, RoHS, WEEE,
FCC, UL, RCM
Thuraya Type Approval

Environmental Conditions

Temperature Operational: -25°C to +55°C (ambient), Storage: -40°C to +85°C
Water and dust IP68
MIL-STD-810G
Temperature shock, solar radiation,
rain, humidity, salt, fog, sand and dust,
immersion, drop, freeze/thaw.
EMI/EMC: MIL-STD-461H

Power

DC input range 12 – 24 VDC (max. 10.8 – 33.6 VDC)
PoE input PoE (802.3bt Type 3 Class 6 via RJ45)
PoE output PoE (802.3at Type 1 Class 2 via RJ45)

Power Consumption

Standby / Transmit 4.5W / 22W (typical)
During charging 75W (max.)

AC/DC power supply

Input 100-240 VAC, 47-63Hz, 64W
Output 19 VDC
Built-in Battery Lithium ion (rechargeable)
Nom. voltage / capacity 10.8 V / 6.9 Ah
Stand-by time Up to 38 hours
Receive Up to 4 hours @ 1024 Kbps
Transmit Up to 3 hours @ 1024 Kbps
Recharge time < 3 hours (0-100%)
Charge temperature 0ºC to 45ºC

Interfaces

WLAN Access Point: 802.11 b/g/n/ac
Ethernet Ports:
1 x RJ45 (PoE input for ext. power)
1 x RJ45 (PoE output IP Handset)
1 x RJ45
USB Port: 1 x USB-C
User interface: 2 x LED (Status and WLAN), Power Button,
Reset Button, Web Interface

Other features

Space42 Connect App: (Available for Android / IOS):Control your IP NEO with your Smartphone
Set-up and Router Functionality:
Webserver, NAT Router, Admin control (password protected), DHCP, Network Management, Remote Management, PPPoE

Package Contents

IP NEO M Terminal with embedded Lithium-Ion Battery
Quick Start Guide
Power Cable, 3m open-ended
Ethernet Cable

Accessories

408052A-24/12 :009V DC cable, 3m open-ended
403650B-923: vPole Mount
408012A-42000: Space42 IP Handset
408016A-42000: Space42 Battery Pack
408016A-010: Space42 42 Battery Pack Extension
408052A-42000: Space42 Mobile Gateway M NEO
408020A-941: IP NEO PoE Cable with RJ-45 screw
408020A-943 IP NEO PoE Cable with RJ-45 screw connectors, 15m

Downloads

Thuraya IP NEO M - Factsheet
