Thuraya MBH

Thuraya MBH is a compact satellite broadband terminal built for reliable connectivity on land and sea. With up to 300/100 kbps IP data speeds and built-in Wi-Fi, it ensures dependable internet access even in remote or low-infrastructure locations. Powered by Thuraya’s L-band network, MBH simplifies mobile satcom without high costs or complexity. Its rugged IP67 and IP68 rating allows it to operate in harsh conditions, while the plug-and-play design makes deployment fast and easy. Features like location tracking, remote programming, and multilingual support make it ideal for mobile teams needing continuous, secure communication wherever they go.

Features

All-in-One Satellite Hotspot

Integrates a built-in modem, Wi-Fi access point, and power management in one terminal for simplified deployment and mobility.

Rapid Plug-and-Play Setup

Install with a single cable and access the web-based interface via mobile or LAN for easy configuration, no training required.

Reliable Data Communications

Supports standard IP speeds up to 300 kbps downlink / 100 kbps uplink over Thuraya’s trusted L-band network.

Ruggedized & Weatherproof

IP67 and IP68 certified to withstand dust, water, and harsh vibration ready for deployment in extreme environments.

Dual-Use Design

One solution for both land-based and maritime applications with optional mounting kits for different use cases.

Emergency-Ready Functions

Equipped with support for tracking, geofencing, distress alert reporting, and remote configuration (This functionality is fully enabled through 3rd party remote server integrations).

Optimized for Modern Systems

Compatible with connected sensors, IIoT platforms, and M2M applications via LAN/Wi-Fi.

User-Friendly Interface

Accessible web menu in 16 languages, including English, Arabic, French, Spanish, Hindi, Turkish, Chinese, and more.

Technical specifications

Dimensions

Terminal: 301 × 181 mm (Ø X H)
PoE Injector: 115 X 90 X 30 mm (L X W X H)

Weight

Terminal: 3.30 kg
PoE Injector: 0.47 kg

Data Capabilities

Standard IP: Up to 300/100 kbps

Vibration

2 ~ 13.2 ~ 100 Hz , 1mm, 0.7gn, 3-axis
5~500Hz, 3-axis

MBH terminal

Wi-Fi: 2.4 GHz (802.11 b/g/n) with WPA/WPA2/WPA3
Ethernet: PoE cable connection from PoE injector
SIM: Nano SIM

Ethernet

• PoE cable connection to Thuraya MBH
• Data towards LAN

Power

PoE Input Range: 12–36 VDC
Standby /Transmit: 16 W / 25 W

Frequency Range

Tx: 1626.5 – 1660.5 (MHz)
Rx: 1525.0 – 1559.0 (MHz)

GNSS Support

GPS, Galileo, Beidou, Glonass

Languages

EN, AR, FA, FR, DE, UR, HI, IT, PT, RU, ES,TR, CN, ID,TH,TL

Approvals

CE, UKCA, RoHS, REACH, ITU GMPCS-MoU, Thuraya certified

Terminal Environmental Conditions

Operational (ambient): -25°C to +55°C
Storage: -40°C to +80°C
Operating humidity: 5% to 95% RH at 40°C
Water and dust: IP67 & IP68

Main package

Thuraya MBH
PoE injector
DC cable (5m)

Land pack accessory

Magnet mount kit
PoE cable (6m)

Maritime pack accessory

Pole mount kit
PoE cable (25m)

Downloads

Thuraya MBH - Factsheet

Thuraya MBH - User Manual
