Thuraya Voyager NEO
Voyager NEO is designed for vehicles that require uninterrupted broadband while in motion. By combining high-speed L-band connectivity with integrated networking and voice services, it eliminates the limitations of terrestrial handoffs and signal loss. Whether deployed for convoy coordination, field fleet management, or mobile command operations, Voyager NEO delivers consistent performance, simple integration, and mission-ready reliability powered by Thuraya-4.
Voyager NEO is designed for vehicles that require uninterrupted broadband while in motion. By combining high-speed L-band connectivity with integrated networking and voice services, it eliminates the limitations of terrestrial handoffs and signal loss. Whether deployed for convoy coordination, field fleet management, or mobile command operations, Voyager NEO delivers consistent performance, simple integration, and mission-ready reliability powered by Thuraya-4.
On-the-Move Broadband Connectivity
Delivers seamless L-band satellite broadband while in motion, ensuring continuous voice and data connectivity across road, rail, and off-road environments.
Powered by Thuraya-4
Leverages next-generation satellite capacity to deliver up to 1024 kbps Rx/Tx with stable performance at low elevation angles.
Instant Vehicle Deployment
Transforms any vehicle into a mobile communication hub within minutes using vehicle-ready mounting and power options.
Integrated Communications Hub
Combines IP data, embedded VoIP/SIP, Wi-Fi access point, and routing in a single compact terminal.
Rugged & Solid-State Design
Low-profile, no moving parts, built to withstand
vibration, dust, rain, heat, and salt in extreme
operating conditions.
Enhanced VoIP & Push-to-Talk
Supports professional voice services including VoIP and Push-to-Talk for coordinated team communications.
Reliable in Harsh Environments
IP68-rated with wide operating temperature range and military-standard environmental compliance.
Global Regional Coverage
Designed for operations across Europe, MENA, Africa, and Central Asia using GEO L-band continuity.
Height: 9.7 cm (without spacers)
Width: Ø 32.1 cm
4.8 kg
> 5° elevation: Up to 1024 kbps (Rx / Tx)
• Standard VoIP
• Embedded SIP Server
• PTT with Mobile Gateway Neo
Tx: 1626.5 – 1660.5 and 1668 – 1675 (MHz)
Rx: 1518.0 – 1559.0 (MHz)
GPS, Galileo, Beidou, Glonassr
EN, AR, FR, DE, ES, RU, JP, CN
CE, RED, RoHS, WEEE, FCC, UL, RCM Thuraya Type Approval
Temperature
Operational (ambient): -25°C to +55°C
Storage: -40°C to +85°C
Water and dust: IP68
Relative humidity
MIL-STD-810G, Test method 507.6
EMI/EMC
EN 01-301489, EN 17-301489,
EN 19-301489
DC input range: 12 – 24 VDC (Max. 10.8 to 32 VDC)
Power (max): 70W (@10.5 – 32V)
WLAN Access Point: 802.11 b/g/n/ac
Ethernet: 10 / 100 / 1000 Mbps
Combined DC power and Ethernet connector
Combined connector providing DC power input,
ignition and Ethernet (PoE 802.3bt Type 3) connectivity.
User interface
One LED (Status), Web Interface,
Reset Button, SIM card connector
Space42 Connect App
Turns a Smartphone into a Satphone.
Available for Android / IOS.
Set-up and Router Functionality
Webserver, NAT Router, Admin control (password protected),
DHCP, Network Management, Remote Management, PPPoE
• Thuraya Voyager NEO Terminal with 3 cm spacers
• Quick Start Guide
• 6m hybrid DC power and Ethernet cable (open-ended)
• 403723B-009: Magnetic Mount kit
• 403706B-050: Connection Box
• 408030A-931: Hybrid DC / Ethernet cable, 6m open-ended
• 408030A-941: PoE connection cable (Cat6A), 6m open-ended
• 408030A-945: PoE connection cable (Cat6A), 25m open-ended
• 408030A-948: PoE connection cable (Cat6A), 50m open-ended
